Rafco X-Press 20
Skip Container Lifting Vehicle. XPress series garbage compactors are design to fit big size three, four axle chassis cabs with a range of 24t GVW, depending on chassis configuration and unladen weight.
Rafco X-Press 20
XPress, compact and very manoeuvrable and ideal solution where restricted access is a problem and excelent manoeuvrability is required.
Features
> Full range of body sizes from 18m³ to 30m³, compatible with all major chassis cabs.
> Hand loading can be achieved by lowering the standard rear drop down rave plate at a moment’s notice. ( Optionally )
> Full compaction ratio 5:1 to 6:1
> Carriage plate cylinder mounted outside of the hooper area, keeping clear of the refuse loading area.
> Ergonomically designed for ease of operation and maintenance .
> Hopper volume: 2 m³ – 3 m³
> Tailgate sweeping cycle time: ~25-35 sec.
> Discharging time: ~45-70 sec.
Xpress 20 Waste Volumes
With Household and recyclable waste
Calculated at 4:1 compaction ratio
Optional Features
• Button control ( Automatic compression cycle )
• EN-1501-1 standards
• Rearview camera, in-can monitor
• Automatic control
• Hardox tailgate
• Container washing system
• 6m³ -10m³ skip container lifting system
